ESAW Multi Meter Analogue (ME-8216)

This pocket Multi meter is a universally usable multi-function instrument. The instrument has been designed in accordance with the most up-to-date safety regulations and ensures safe, reliable measurement. It is a useful aid, for all standard measurements, to the electrician on site, in industry or for hobby electronics. Analogue Display DC and AC voltage measurements up to 1000V DC current measurement up to 250mA. Resistance measurement up to 2M?

Operating temperature: 0-40°C, max 75% RH

Display: Analogue display Meter

Battery: 1.5V battery

Function Range Accuracy

DC : 0 - 2.5/10/50/1000V t 5%

AC : 0 -10/50/250/1000V ± 5%

DC : 0 - 10/250mA ± 5%

RESISTANCE 0-20k? /2M? (R x 10 / Rx 1k) ± 5%

BAT TEST 1.5V (250mA) / 9V (10mA) ± 10% (Middle of GOOD line)

Resistance of meter DC 10k? N, AC 4.5k? N
