ESAW panel Meters (ME-8243)

(A) MO-65, Round: Unbreakable, moulded, ABS Plastic Black Case; Accuracy ±2.0 FSD; Scale Length about 50mm with knife edge pointer, with or without anti-parallax mirror scale; Overall Size about 80mm round; flush type mounting.

(B) MR-100, Rectangular: Unbreakable, moulded, ABS Plastic Black Case with clear transparent front window; Accuracy 32.0 FSD; Scale Length about 85mm with knife edge pointer, with or without anti-parallax mirror scale; Overall Size about 80x 100mm rectangular; flush type mounting.

METERS ON DESK STAND: All meters provided with 4mm colour coded terminals for connections. Sloping face for bench use provides convenient reading.

(C) MO-65, Round, Desk Stand: Unbreakable, moulded, ABS Plastic Black Case; Accuracy ±2.0 FSD; Scale Length about 50mm with knife edge pointer, with or without anti-parallax mirror scale; Desk stand with 4mm terminals at the top; Overall Size about 90 x90 x 110mm.

(E) EDM-80: Unbreakable, moulded, ABS Plastic Black Case with clear transparent front window; Accuracy ±2.0 FSD; Scale Length about 65mm with knife edge pointer, with or without anti-parallax mirror scale; Desk stand with 4mm terminals at the front; Overall Size about 120 x80x85mm.

(F) MR-100, Rectangular: Unbreakable, moulded, ABS Plastic Black Case with clear transparent front window; Accuracy ±2.0 FSD; Scale Length about 85mm with knife-edge pointer, with or without anti-parallax mirror scale; Desk stand with 4mm terminals at the front; Overall Size about 100x 100x 140mm.

(G) EDM-100: Unbreakable, moulded, ABS Plastic Black Case with clear transparent front window; Accuracy ±2.0 FSD; Scale Length about 85mm with knife-edge pointer, with or without anti-parallax mirror scale; Desk stand with 4mm terminals at the front; Overall Size about 110 x100 x 140mm.
