ESAW Training Board for the study of Power Supply Solid State (EEC-10529)
The setup consists of a step down transformer, rectifier circuit (can be used as a half wave or a full wave rectifier) a filter circuit (on inductance and two capacitors)—the b arrangement can be used for the study of various configuration of filters and a regulation circuit. The following studies can be carried out with this set-up
1, Study of rectification
(a) Full wave rectification
(b) Half wave rectification
2. Study of AC
(a) Efficiency of various types Ripple: Component of filters- T type etc.
(b) The effect of load
(c) The effect of regulation
3. Regulation characteristics :
(a) Effective load on regulation
(b) The effect of change in mains voltage
Specifications :
ORS =12v 01s
Maxicurrent = 200 mA 1%
